Gas cylinder bundle, also known as a cylinder pack or gas cylinder manifold system, is a modular gas storage and supply solution that integrates multiple high-pressure cylinders through a manifold system.
| Specification: | 2×2 |
|
Working pressure: |
25 |
|
Geometric valume: |
8 |
|
Specification(OD×length mm)： |
φ559×10290 |
|
Weight（Kg）: |
14900 |
|
Size(Length×width×height): |
11450×1340×1500 |
Contate-nos
PRODUTOS QUENTES
Descrição detalhada
Especificação
Vídeo
[excel | 2025.05.06]
High-Density Gas Storage Advanced Cylinder Rack Systems
Gas cylinder bundle is a modular gas storage solution composed of multiple high-pressure cylinders integrated through an intelligent manifold system, specifically designed for applications requiring continuous gas supply, high flow output, or redundant gas backup.
| Especificação | Working pressure | Geometric valume | Especificação (OD×length mm) | Qty | Weight（Kg） | Size (Length×width×height) |
| 2×2 | 25 | 8 | φ559×10290 | 4 | 14900 | 11450×1340×1500 |
Through centralized control and integrated safety linkage design, it significantly enhances gas usage efficiency and reduces the frequency of cylinder replacement, making it suitable for applications in medical, industrial, energy, and laboratory fields.
| 559 Bottle group parameters | |||||||
| Especificação | Arrangement | Working pressure (Mpa) | Geometric valume (m³) | Specification(OD×length mm) | Qty | Weight (Kg) | Size(Length×width×height) |
| 1×3 | ○ ○ ○ |
25 | 6 | φ559×10290 | 3 | 11000 | 11450×680×2150 |
| 2×2 | ○○ ○○ |
25 | 8 | φ559×10290 | 4 | 14900 | 11450×1340×1500 |
| 2×3 | ○○ ○○ ○○ |
25 | 12 | φ559×10290 | 6 | 22300 | 11450×1340×2150 |
| 1×3 | ○ ○ ○ |
25 | 3.39 | φ559×5900 | 3 | 6600 | 6755×680×2150 |
| 2×2 | ○○ ○○ |
25 | 4.52 | φ559×5900 | 4 | 8700 | 6755×1340×1500 |
| 2×3 | ○○ ○○ ○○ |
25 | 6.78 | φ559×5900 | 6 | 13000 | 6755×1340×2150 |
| 1×3 | ○ ○ ○ |
25 | 3.9 | φ559×6750 | 3 | 7600 | 7605×680×2150 |
| 2×2 | ○○ ○○ |
25 | 5.2 | φ559×6750 | 4 | 10000 | 7605×1340×1500 |
| 2×3 | ○○ ○○ ○○ |
25 | 7.8 | φ559×6750 | 6 | 15100 | 7605×1340×2150 |
| 3×3 | ○○○ ○○○ ○○○ |
25 | 8.28 | φ559×4850 | 9 | 16500 | 5475×2160×2150 |
| 715 Bottle group parameters | |||||||
| Especificação | Arrangement | Working pressure (Mpa) | Geometric valume (m³) | Specification(OD×length mm) | Qty | Weight (Kg) | Size(Length×width×height) |
| 1×3 | ○ ○ ○ |
25 | 6 | φ715×6550 | 3 | 12600 | 7550×840×2630 |
| 2×2 | ○○ ○○ |
25 | 12 | φ715×9550 | 4 | 23400 | 10700×1715×1860 |
| 2×3 | ○○ ○○ ○○ |
25 | 18 | φ715×9550 | 6 | 35000 | 10700×1715×2630 |
| 3×3 | ○○○ ○○○ ○○○ |
25 | 18.00 | φ715×6550 | 9 | 36600 | 7550×2470×2630 |
